Applications
Kitchens, retail stores, warehouses, and industrial applications
Standard dimensions
Shutter skin thickness: 0.80mm
Shutter dimensions(mm): Width : 1200 mm to 2300 mm Height: 1800- mm to 2500 mm
Shutter thickness: 46mm
Frame skin thickness: 1.20mm
Frame dimensions: 100 x 75 mm
Frame thickness: –
Rawmaterial used
Skin Pass Galvanized Iron Sheet (Conform to IS277)
Infill material
Shutter: Honeycomb Kraft paper
Frame: Polyurethane foam
Accessories
Hinges, Locks, Flush bolts (double door), Door closer
Vision Glass
–
Louvres
–
