Applications
Elevator systems, Maintenance and service access, Fire protection, Sound insulation, Security and access control, Energy efficiency, Aesthetics and design integration
Standard dimensions
Shutter skin thickness: 1.20mm
Shutter dimensions(mm): Width : 400 mm to 1500 mm ( Single Door upto 1200 mm)
Height: 500- mm to 2000 mm
Shutter thickness: 25mm
Frame skin thickness: 1.20mm
Frame dimensions: 80 x 58 mm,80 x 78 mm,100 x 58 mm , 100 x 78 mm
Frame thickness: –
Rawmaterial used
Skin Pass Galvanized Iron Sheet (Conform to IS277)
Infill material
Shutter: Honeycomb Kraft paper
Frame: Polyurethane foam
Accessories
Hinges, Locks, Flush bolts (double door), Door closer
Vision Glass
–
Louvres
Factory finished and fixed Metal Louvers (sight proof) can be provided in Square / Rectangular sizes.
